ASTM A105 Lap Joint Flange 300LB

Carbon Steel Flange Price List

Reasonable price and great service by carbon steel flange manufacturer which offer 3″ Sch40 ASTM A105 Lap Joint Flange RF 300 LB ASME B16.5 for Lebanon.

Lap Joint or Van Stone flanges are used on piping equipped with lap joint stub ends or with lapped pipe. They may be used at all pressures and are available in a full size range. These flanges slip over the pipe, and are not welded or otherwise fastened to it. Bolting pressure is transmitted to the gasket by the pressure of the flange against the back of the pipe lap

A105 Lap Joint Flange Dimensions

Size: 3 Inch

Pressure: 300 LB

Seal Type: Raised Face

Seal Thickness: SCH 40

Standard: ASME B16.5

A105 Lap Joint Flange Dimensions

A105 Lap Joint Flange Dimensions

ASME B16.5 Forged Flanges

Inspection

Inspecting Carbon Steel Forged Flanges according to ASME B16.5 Standard.

QA/ QC person visual check surface and marking, and measure the size.

Third party inspection: BV, SGS, LR, DNV, ABS and Stamp the mill test certificate.

ASTM A105 Chemical Composition

C Mn P S Si
0.15 0.6-1.05 0.035 0.04 0.1

ASTM A105 Mechanical Properties

Tensile Strength Yield Strength Elongation
485  (Mpa) 250  (Mpa) 30 (%)

Forged A105 Pipe Flanges

Surface Treatment

All carbon steel forged flanges are normalized heat treatment before delivery.

ANSI Flange Dimensions Chart

Standard ASME B16.5, API 5A
Diameter 1/2 to 24 inch / DN15-DN600
Pressure Class 150, 300, 600, 900, 1500, 2500
Product Slip On Flange, Threaded Flange, Socket Weld Flange, Blind Flange,
Lap Joint Flange, Weld Neck Flange.
Stainless Steel ASTM A182 F316/316L, F304/304L, SS317, SS321, SS310
Duplex Steel ASTM A182 F51, F53, F55
Carbon Steel ASTM A105, A350 LF2, LF3
Alloy Steel ASTM A182 F1, F5, F9, F11, F12, F22 ,F91

Steel Flange Fittings 3 Inch

Package

Packed 3 Inch ASTM A105 Lap Joint Flanges into wooden pallet.

Forged Flanges and Fittings

Shipping

Delivery port: Shanghai, Tianjin, Qingdao

Lead time: 10 days are ready to deliver

Shipment: LCL, 20GP, 40GP, Air, Courier

Document: CI, PL, CO, BL, MTC

Certificate: CE, ISO, TEST REPORT

Export Country

Asia: Vietnam, Singapore, Thailand, Indonesia, Malaysia, Philippines, Kazakhstan.

Africa: Nigeria, Madagascar,Ghana, Kenya, Angola, Tanzania, South Africa.

Middle East: Saudi Arabia, Qatar, Israel, Egypt, Oman, Yemen, Jordan, Lebanon.

Latin America: Uruguay, Peru, Chile, Brasil, Ecuador, Colombia, Argentina, Paraguay

Oceania: Papua New Guinea, Australia, New Zealand, Solomon Islands, Fiji.

Europe: Greece, UK, Poland, Ukraine, France, Spain, Portugal, Norway, Sweden
