ASTM A53 Galvanized Tube
A53 Galvanized Tube
We are manufacturer of Galvanized Tube and providing 2 Inch Sch80 ASTM A53 Gr B Galvanized Tube for UAE. They are one of the most widely used carbon steel pipe in oil and gas as well as other process industries. It more suits for structural and non-critical application. They are not suitable for hydrocarbon services or any services with high pressure and temperature.
Hot dip galvanizing is a widely used coating for carbon steel pipes, it will be corrosive first so that the pipe can be more durable. A53 pipe usually provided with galvanized coating.
A53 Grade B Pipe Feature
Size: 2 Inch
Thickness: Sch80
Surface: Galvanized
Material: ASTM A53
Grade: Grade B Pipe
ASTM A53 Specification
Meaning & Specification
ASTM A53 is a standard, covers seamless & welded black and hot dipped galvanized steel pipe in 1/8” to 26”. It allows pipes having other dimensions as long as such pipes complies with all requirements of the standard. Those materils are commonly used as structural steel or for low pressure plumbing.Three types and two grades are involved.
A53 Type F: Only Grade A available in welded pipe type.
Type E: Grade A and Grade B for electric resistance welded pipe.
Grade S: Seamless pipe made by hot working Grade A and Grade B.
A53 Grade B is more popular grade among them.
Chemical Composition of Grade B Pipe
| C | Mn | P | S | Cu | Ni | Cr | Mo |
|---|---|---|---|---|---|---|---|
| 0.3 | 1.2 | 0.05 | 0.045 | 0.4 | 0.4 | 0.40 | 0.15 |
Grade B Pipe Mechanical Properties
| Tensile Strength | Yield Strength |
|---|---|
| 415 | 240 |
Galvanized Carbon Steel Tube
A53 Galvanized tube
What is galvanized A53 Pipe?
It is dipped the A53 Grade B pipe into zinc bath to prevent rust as well as providing a harder surface. The price of galvanized pipe is on the low end of pricing. Carbon steel pipe usually need this coating because they are not good at corrosion resistance.
Carbon steel tube
It is the most commonly used material for process piping. Compared the pipes, tube usually has smaller diameter. It has the advantages of wide availability, high strength, and great cost advantages. There are many grades of carbon steel pipe and they are available in a number of sizes and wall thickness.
| Carbon Steel Pipe | ASTM A53, A106 B, API 5L B, X42, X46, X52, X56, X60, X65, X70, |
|---|---|
| Dimensions | 1/8″ to 48″ |
| Wall Thickness | Sch 10, 20, STD, 40, XS, 80, 100, 120, 140, 160, XXS |
| Type | Seamless & Welded |
| Coating | A53 Galvanized Tube, Black Primer, PE, 3PE |
