20# OD108 x 4mm Steel Pipe
20# Steel Pipe
We are manufacturer of Steel Pipe and providing 20# Steel Pipe 108 x 4mm x 11.5m GB3087-2008 for Vietnam.
Carbon steel can be divided into low carbon steel, medium carbon steel and high carbon steel. Low carbon steel means the content of carbon is lower than 0.25%, medium carbon steel contains carbon between 0.25% to 0.6%, and high carbon steel carbon contents is usually larger than 0.6%. 20# carbon steel pipe belongs to low carbon steel, 20 means the carbon content is 0.2%. It is high quality carbon steel with good toughness, plasticity and weldability but low strength.
GB3087 Pipe Feature
Size: 108 x 4mm
Length: 11.5m
Material: China Grade 20 Pipe
Surface: Painting
Package: In Bundle
A105 VS 20# Steel Pipe
A105 is American standard low carbon steel for forged pipe fittings, its mechanical properties is similar with 20# but the strength is higher. As line pipe materials, A105 can replace 20# steel but 20# steel cannot complete replace A105 because of the strength difference. The corrosion resistance of 20# steel is better than A105. Therefore, A105 usually is used as material of forged flanges and pipe fittings, while 20# is used as materials for line pipe, valves and other equipments.
20# Steel Pipe Chemical Composition
C | Si | Mn | P | S | Ni | Cr | Cu |
---|---|---|---|---|---|---|---|
0.17-0.23 | 0.17-0.37 | 0.35-0.65 | 0.035 | 0.035 | 0.3 | 0.25 | 0.25 |
Grade 20 Pipe Mechanical Properties
Tensile Strength | Yield Strength | Elongation |
---|---|---|
253-500 | 275 | 25 |
Carbon Steel Pipe Sizes
There are three ways to describe the diameter of 20# steel pipes.
- NPS: Refers to Nominal Pipe Size, it is a north American set of standard sizes for pipes. The sizes are measured in inch.
- DN: European and international designation equivalent to NPS, its unit is mm, see ISO 6708. NB is also frequently used interchangeably with DN.
- OD: OD is the outside diameter of the pipe. For NPS 1/8 to 12, NPS and OD values are different. For NPS 14 and up, they are equal. The unit of OD can be inch or mm.
Supply Range of Steel Pipes
Diameter | 1/2” to 48”, or 15mm to 1200mm |
---|---|
Thickness | Schedule 5S – Schedule XXS |
Length | Single Random, Double Random & Required Length |
Steel Pipe Type | Seamless pipe and Welded pipe Grade 20 Pipe |
End | Plain End, Beveled End, Treaded |
Carbon Steel Pipe Materials
ASTM/ ASME A 105, ASTM/ ASME A 350 LF 2, ASTM / ASME A 53 GR. A & B, ASTM A 106 GR. A, B & C. API 5L GR. B, API 5L X 42, X 46, X 52, X 60, X 65 & X 70. ASTM / ASME A 691 GR A, B & C, 20#, Q235
Advantages of ZIZI Carbon Steel
- Variety and high quality products.
- Factory direct sales, low cost
- Large inventory, in time delivery
- Rich experience, attentive service
- Customer trusted manufacturer
