Flange Sets Professional Supplier

The Weld Neck Flanges, Spiral Wound Gaskets and Stud Bolts are full sets for connecting with valves that called Flange Sets. Compared with other connectors, flange connection is more convenient and more reliable. So, many customers choose it for its good sealed and detachable performance. And here a Vietnam customer purchased a mass of flange fittings.

Flanges and Accessories Order

On receiving an inquiry, our professional seller Wendy began to handle it. Customer needed flange sets which are A105N Flanges, SS316 Gasket and A193 B7 Stud Bolts. After checking every details about inquired products and shipment, the reasonable price was offered though her comparing with our stable suppliers.

Some back-and-forth communication, we offered a more competitive price basing on building a good cooperation with the new client. During the negotiation, Mr. Tuan requested some discount, however, we put the quality on the top as well as shorten the delivery time to 12 days. Mr. Tuan totally agreed with us. At the end, the order was finally confirmed happily and with great satisfactions.

From raw materials to finished products, we guaranteed high-quality stainless steel 316, carbon steel A105N, and A193 B7 supplement. The process was also followed up by our quality controller every day. All of these have been to make sure we can finish the production on time.

After deliver the goods, we provide the CI, PL.BL and A105N Weld Neck Flange MTC, SS316 Spiral Wound Gasket MTC, A193 B7 Stud Bolt MTC

Flange Sets Order Details

S/NO	Description			Qty (Set)
1	2PCS Flange WN 6″ #150 Sch80, RF, ASTM A105N 2PCS Spiral Wound Gasket 6″ #150 RF, ASTM SS316 16 PCSStud-Bolt M20x115 A193 B7			4
2	2PCS Flange WN 2″ #150 Sch80, RF, ASTM A105N 2PCS Spiral Wound Gasket 2″ #150 RF, ASTM SS316 8PCS Stud-Bolt M16x95 A193 B7			16
3	2PCS Flange WN 10″ #600 Sch160, RF, ASTM A105N 2PCS Spiral Wound Gasket 10″ #600 RF, ASTM SS316 32PCS Stud-Bolt M33x215 A193 B7			3
4	2PCS Flange WN 8″ #600 Sch160, RF, ASTM A105N 2PCS Spiral Wound Gasket 8″ #600 RF, ASTM SS316 24 PCS Stud-Bolt M30x195 A193 B7			4

Inspection for Flange Sets

6 Inch Weld Neck Flanges Inspection

6 Inch Flanges were inspected according to ASME B16.5 standard.

Surface: Visual check and hand touch, they are smooth without defect

Marking: Check the marking content if they are correct. For example, the description of Flange WN 6″ #150 Sch80, RF, ASTM A105N were marked as “6 Inch 150# WN RF SCH80 ASTM A105N ASME B16.5 16083”

Pressure and Size: Measure the diameter of flange hole, thickness of flange and raised face.

Stainless Steel 316 Gasket Inspection

SS316 Gasket were inspected according to ASME B16.20 standard.

Material: Used the spectrograph to test the main chemical data.

Size: Measured Spiral Wound Gasket Dimension D1, D2, D3, D4 and T.

Marking：Checked if “Spiral Wound Gasket 8″ #600 RF, ASTM SS316” were marked as “8″ 600# 316+316/FG+316”

A193 B7 Stud Bolts Inspection

These Stud Bolts were inspected according to ASME B1.1 standard.

Size: Measured the bolts diameter and length. Checked nuts type and fit with both end of stud bolts.

Flange Sets Package

• A193 B7 Stud Bolts were packed in waterproof paper bags. We marked the size and quantity on each bag, such as 27 sets of M30x195 Stud Bolts.
• SS316 Spiral Wound Gaskets were put into small wooden cases which filled with soft material to avoid the damage.
• A105N Weld Neck Flanges surface were painted black and packed in big wooden case. Each flanges were wrapped with plastic foam.

We marked the packing list and shipping mark on each wooden cases for picking easily by customer.

A lot of detailed packages have been taken before delivery. Every step has been supervised by our staff.

Feedback

As per contracted date, flange sets which are almost 500 pieces flange and Accessories have been safely shipped to our client. All jobs have been praised by them which lay the foundation for our long-term business relationship.
